HELIOS 350-V PROFILE PROJECTORS Ø 350 MM VERTICAL PROJECTION Helios 350-V Benchtop Profile Projector for vertical projections with 350mm goniometric screen with grid. Permissible weight of 15 Kg on the workpiece table.
Categories : Optical measurement , Metrology Product , Optical measurement , Profile projector , Horizontal Profile projector , Special Promotion , Clearance sales ,
Brand : MICROTECNICA
Share
HELIOS 350-V PROFILE PROJECTORS Helios 350-H is a benchtop profile projector with horizontal projection especially for checking cylindrical pieces, to be placed between the tailstocks, or on “V” supports, as well as for parts to be fixed in a vice.
The standard composition of the Helios models includes linear transducers and rotary encoder, as well as the new 780 M-Touch touch screen display/data processor. This new system allows direct measurements to be taken in the two coordinates and angular, in addition to the processing of the main geometric functions.
The device is complete with an optical sensor for automatic collimation on the screen (exclusively with diascopic projection).
Technical Specification
Download Product Literature
