Automated measurement and complex measurment solutions

Automatic measurement in CNC machines

Lower total operating costs due to higher degree of automation.

100 % In process measurement with DIATEST BMD bore gauge - in your CNC machine!

Whether turning, milling, grinding -

• The plug gauge BMD is located in the toll chaning system of the CNC machine.

• Standard tool holders can be used - for various diameters

• No conversion of the CNC machine to measured value display - Integration into DIAWIRELESS real radio network

• Very high repeatability accuracy

• Floating holder for compensating positioning errors

• All BMD sizes possible - from 3,95 mm to 100 mm

• Independent of machine manufacturer

• Less human intervention required, less rework, special releases or rejects

Measuring in the process - 100 % safety in the process

  Download Flyer automated measurement in CNC machines.

Video : Cycle time left? Automatic measurement in CNC machines

Video : Combined automatic measurement in CNC machine and robot supported measuring cell.
